TAYLOR 8250 Series Safety Relief Valve

Air

Gas

Liquid

TAYLOR 8250 Series Safety Relief Valve

Air

Gas

Liquid

Inlet Sizes

DN15 - DN80 | 1/2" - 3"
(Threaded NPT or Flanged)

Pressure Rating

1.03 - 689 bar | 15 - 10,000 psig *

Temperatures

-251°C to 260°C

Approvals

ASME VIII Div 1 (Air, Gas & Liquids)

Downloads

Applications

8250 Threaded & Flanged Valves

The Taylor 8250 Safety Relief Valve is manufactured in accordance with the requirements of ASME Boiler and Pressure Vessel Code, Section VIII, Division 1 for Air/Gas and Liquid service making it an excellent choice for Air, Gas or Liquid relief applications, including Compressors, Separators, Heater Treaters, Free Water Knockouts, Scrubbers, Dehydrators, Thermal Relief, Gas Production Units,Transmission and Gathering Lines, Chemical Plants, Refineries, Meter Runs, Gas Plants and other Industrial Applications.
Features
Features Include:
- Designed with self-aligning seat technology.
- C orifice with pressure to 10,000 psi *.
- A large range of elastomer materials to suit a variety of high variance pressure & temperature configurations.
- Increased capacity in all orifices compared to older 8200 series.
- Top entry style valve H orifice and larger.
- API connections available in most flanged connections.
- All orifices are ASME certified by the National Board of Boiler and Pressure Vessels in accordance to Sec VIII Div I. for air/gas and liquid service.
Options
Options Include:
- Open & Gas-tight lift levers
- NACE Approval Specification
- 1/4″ NPT Top Cover Tap
- VITON, PTFE, EPDM, PEEK, PC BUNA Seating elastomers.
Datasheets

Series 8250 Datasheet
